l30g Compact Wheel Loaders

Product ID: L30G
Description

Experience superior performance in the robust Volvo L30G. Built to work hard, the versatile L30G is packed with safety and performance-enhancing features including high quality attachments, comfortable cab, state-of-the-art hydraulics, easy-to-use controls and superb serviceability. Operate with confidence and control in the durably designed L30G compact wheel loader.

Features and Benefits
  • Comfortable cab
  • Excellent hydraulics
  • Easy-to-use controls
  • Outstanding serviceability
  • Wide range of attachments
  • Lifetime Frame & Structure Guarantee Frame (Articulation Joint, Loader Arm)
  • Brochures
  • Featured Specifications
  • Full Specifications
Engine Output - Gross
Imperial Unit hp
Imperial Value 74
Metric Unit kW
Metric Value 55.4
Unicode e60b
Bucket Capacity
Imperial Unit yd 3
Imperial Value 1.2 - 2
Metric Unit m 3
Metric Value 0.9 - 1.5
Unicode e60f
Operating Weight
Imperial Unit lbs
Imperial Value 12125
Metric Unit kg
Metric Value 5500
Unicode e605
Driveline
Engine Manufacturer Volvo
Engine Model D4J
Emissions Technology Cooled Exhaust Gas Recirculation
After Treatment System Diesel Particulate Filter
Aspiration Turbo
Displacement 244 Inches³ (4 ltr)
Rated Speed 2200 rpm
Engine Output - Gross 100 hp (75 kW)
Engine Output - Net 97.9 hp (73 kW)
Torque 314 lbf / ft (425 Nm)
Transmission Type Hydrostatic
Traction Control Yes
Tire Size - Standard 15.5 - 25
Hydrostatic System Braking Yes
Hydrostatic Brake - Actuation All Wheels
Service Brake - Type Wet Disc
Dimensions
Wheelbase 8 ft 7 in (2650 mm)
Length With Bucket On Ground 20 ft 10 in (6385 mm)
Height - Over Cab 9 ft 8.1 in (2950 mm)
Ground Clearance 15.5 inches (395 mm)
Width Over Tires - Std 7 ft 0.6 in (2150 mm)
Bucket Type GP w/Edge
Bucket Width 7 ft 4.6 in (2250 mm)
Full Lift Dump Height 9 ft 1.4 in (2780 mm)
Full Lift Reach 3 ft 1.8 in (960 mm)
Loader - Geometry Torque Parallel
Dump Angle - At Dump 45 °
Dump Angle - Maximum 45 °
Height - Pivot Pin 12 ft 1 in (3685 mm)
Height - Maximum 18 ft 8.2 in (5695 mm)
Turn Radius Over Bucket - Std. 16 ft 11.15 in (5160 mm)
Capacities
Fuel Tank 42.3 gallons (US) (160 ltr)
Heaped Capactiy 2 yd³ (1.5 m³)
Bucket Capacity - Smallest 1.6 yd³ (1.2 m³)
Largest Bucket Capacity 2.6 yd³ (2 m³)
Performance
Straight Tipping Load 12919 lbs (5860 kg)
Full Turn Tipping Load 11442 lbs (5190 kg)
Breakout - Bucket 15601 lbf (7076.49 kgf)
Bucket Breakout 15601 lbf (69.4 kN)
Ride Control System Optional
Load Sensing Yes
Weights
Bucket Capacity 1.6-2.6 yd³ (1.2-2 m³)
Operating Weight 19378 lbs (8790 kg)
